High-Quality CE Hydraulic Triple Level Car Parking Lifter for Home Garage Factories, Factory

The new CHFL4-3 Triple Level Car Stacker is a highly efficient and affordable solution for maximizing parking density by accommodating three vehicles within the footprint of one standard parking space. Designed for versatility, it supports 2000 kg or 2500 kg on the upper platform and 3000 kg on the middle platform, while the ground level has no weight limitation, allowing it to hold heavier vehicles. This makes the system suitable for a wide variety of vehicle types, including sedans, SUVs, sports cars. Its robust structure, reliable safety features, and space-saving design make it ideal for residential, commercial, and professional parking applications.

Product Description

Products Feature

Triple Stacker Lift Feature
1. Space Optimization: The Triple Stacker Lift is engineered to vertically stack and lift three cars, effectively utilizing vertical space and reducing the horizontal footprint required for parking.
2. User-Friendly Operation: A user-friendly control system allows drivers to easily park and retrieve their vehicles with minimal effort.
3. Safety and Security: Multi lock release system to keep safe. And there is emergency button.
4. Lifting Capacity: 2000kg per level or 2500kg per level.

Specifications

Parameters NEW CHFL4-3 Sedan NEW CHFL4-3 SUV
Lifting Capacity Ground Floor Unlimited,
Lower Level 2700 kg,
Upper Level 2000 kg
Ground Floor Unlimited,
Lower Level 3000 kg,
Upper Level 2000 kg
Ground Floor Usable Height 1600 - 2100 mm 2100 mm
Second Floor Usable Height 1300 - 1800 mm 2100 mm
Column Height 4100 mm 4896 mm
Total Length 5750 mm 6200 mm
Total Width 3000 mm 3000 mm
Usable Width 2367 mm 2367 mm
Power 220/380V 50/60HZ 1/3Ph 2.2Kw
Operation Model Key Switch + Button
Drive Mode Hydraulic Drive + Steel Wire Rope

Drawing & Case

Technical Drawing
Triple Stacker Case 1 Triple Stacker Case 2 Triple Stacker Case 3

Frequently Asked Questions

What is the maximum lifting capacity of the Triple Stacker Lift?
The lift can handle 2000kg to 2500kg per level depending on the configuration. For specific models like the SUV version, the lower level can handle up to 3000kg.
What safety features are included?
The system is equipped with a multi-lock release system and an emergency stop button to ensure the highest safety standards during operation.
Can the Triple Stacker accommodate SUVs?
Yes, we offer a dedicated SUV model (NEW CHFL4-3 SUV) with increased column height (4896 mm) and usable height (2100 mm) for both levels.
What are the power requirements for installation?
The system requires a power supply of 220/380V, 50/60HZ, 1 or 3 Phase, with a 2.2Kw motor.
How is the lift operated?
The lift uses a simple and reliable Key Switch + Button operation model, making it user-friendly for all drivers.
What is the drive mechanism of this parking lift?
It utilizes a Hydraulic Drive combined with Steel Wire Ropes for smooth and stable lifting performance.
