High-Quality Hydraulic Electric Manual Four Post Car Lift for Parking And Repair Manufacturer, Factories

CHFL3700E Four-Post Car Lift – High Stability, Enhanced Protection, and Smooth Operation
The CHFL3700E is a robust, hydraulically powered four-post car lift designed for safe vehicle storage, repair, and daily parking needs. Engineered with a multi-position mechanical locking system, it delivers exceptional stability and ensures maximum operational safety. Its durable structure supports a wide range of vehicles—from sedans to SUVs and light trucks—making it ideal for both residential garages and commercial workshops.
Thanks to its efficient space-saving design, the lift allows vehicles to be stacked vertically, effectively increasing parking capacity without requiring additional floor space. Easy to operate, reliable, and built for long-term performance, the CHFL3700E is an excellent solution for users seeking dependable lifting and storage capability.

Product Description

Products Feature

Product Feature 1
⚙️
Easy to operate and well-designed, with a load-bearing capacity of 3500 kg to handle a variety of vehicles efficiently.
↕️
The platform can stop at different heights to adapt to various vehicles and ceiling heights, suitable for low-profile cars or high-ceiling garages.
💎
The platform runway and ramps are made of diamond-shaped steel plates, offering high strength and stability.
🛡️
The ramps have anti-slip surfaces to enhance safety, especially in wet or slippery conditions.
🧱
Each column is equipped with anti-shake sliders to keep the platform stable and reduce vibrations during operation.
Electric/hydraulic power system provides precise control and strong power by combining the advantages of both.
🔧
A single hydraulic cylinder installed below the runway simplifies the structure and ensures smooth lifting.
🔒
Anti-fall mechanical locks at different heights on all four columns prevent the platform from falling in emergencies.
🔘
Button-type pneumatic safety release enables quick and easy activation of the safety mechanism.
🎨
Powder-coated surface treatment for indoor use or hot-dip galvanized for outdoor use to protect against corrosion.
Product Feature 2

Specifications

Model No.CHFL3700
Lifting CapacityMax 3500kg
Lifting Height1965mm
Height of Post2276mm
Outside Edge of Runways1897mm
Overall Width2667mm
Outside Length4883mm
Operation ModeKey Switch + Button
Power Supply / Motor Capacity220/380v, 50 / 60Hz, 1/3Ph, 2.2Kw
Drive ModeHydraulic Drive + Steel Wire Rope

Drawing & Case

Drawing
Case 1
Case 2
Case 3

Common Questions (FAQ)

What is the maximum weight capacity for this lift?
The system is designed with a heavy-duty load-bearing capacity of up to 3500 kg, making it suitable for SUVs, sedans, and other passenger vehicles.
Can this parking lift be installed outdoors?
Yes. While the standard version is powder-coated for indoor use, we offer a hot-dip galvanized surface treatment specifically designed to resist corrosion in outdoor environments.
How does the safety locking mechanism work?
The lift features anti-fall mechanical locks at multiple height intervals on all four columns. In the event of a hydraulic failure, these locks engage automatically to secure the platform.
Is it possible to adjust the lifting height?
Absolutely. The platform can be stopped at various height settings to accommodate different vehicle profiles and varying ceiling heights in your garage.
What type of maintenance is required for the hydraulic system?
The single hydraulic cylinder design simplifies maintenance. We recommend regular inspections of the steel wire ropes and hydraulic fluid levels to ensure smooth and long-term operation.
