Our four post car stacker lift is an innovative two-level parking solution capable of holding up to four vehicles—two on the upper level and two on the lower. With a robust load-bearing capacity of up to 3,000 kg, it safely accommodates a wide variety of vehicles. What sets this system apart is its unique double-wide design, allowing simultaneous lifting, lowering, and storage of two cars at once. This maximizes parking efficiency while delivering unmatched convenience for both home and commercial use.

Send Inquiry

Product Description

Products Feature

4 Cars Four Post Parking Lift
✓
Double-wide design that can accommodate four vehicles. This design efficiently utilizes space, enabling users to park four cars in a single setup, which is highly practical for areas with limited parking space.
✓
Customizable according to the layout. Its compact design not only saves space but also cuts down costs. Whether it's a small garage or a large-scale parking lot, it can be tailored to fit the specific needs.
✓
Dual safety locks are provided. The first one is an integrated adjustable safety lock ladder, and the other automatically activates when the wire rope breaks. This double-protection mechanism ensures the safety of parked vehicles.
✓
The runway can accommodate both wide and narrow vehicles. It is designed with flexibility in mind, allowing different types of cars to enter and exit without any issues.
✓
It has a total lifting capacity of 3000 kg. This substantial capacity makes it suitable for lifting a variety of vehicles, from sedans to SUVs.
✓
Each column is equipped with multi-position safety locks. These locks offer multiple locking options, enhancing the stability and safety of the entire structure.
4 Cars Four Post Parking Lift Operation
✓
There is a hidden single hydraulic cylinder. This design not only gives a sleek look but also ensures smooth and efficient operation.
✓
Increasing the pulley diameter reduces cable fatigue. This measure extends the service life of the cables, leading to less maintenance.
✓
The mechanical anti-fall locks allow for multiple stop heights. It provides users with more control over the lifting process, making it convenient for different parking and maintenance requirements.
✓
The position of the power unit and control panel can be customized. This flexibility enables installation in various environments and makes operation more user-friendly.
✓
Protective devices prevent wire rope loosening and breakage. These devices add an extra layer of safety to the equipment.
✓
Surface treated with powder coating. Provides an aesthetic appearance and protects against corrosion, ensuring long-term durability.

Specifications

Model No.CHFL2+2
Lifting Capacity3000 kg
Lifting Height1965 mm
Width between Runways3823mm
Lock DeviceDynamic
Lock releaseElectric auto release
Drive ModeHydraulic Driven + Cable
Power Supply / Motor220/380v, 50/60Hz, 1/3Ph, 2.2Kw
Safety DeviceAnti-falling Device
Operation ModeHydraulic Drive + Steel Wire Rope

Drawing & Case

Technical Drawing
Parking Lift Case 1
Parking Lift Case 2
Parking Lift Case 3

Frequently Asked Questions

What is the total lifting capacity of the CHFL2+2 model?
The system has a substantial total lifting capacity of 3000 kg, making it suitable for a wide range of vehicles from standard sedans to larger SUVs.
How does the safety locking mechanism work?
It features a dual safety system: an integrated adjustable safety lock ladder and an automatic activation lock that triggers if a wire rope breaks, ensuring maximum vehicle security.
Can the lift be customized for different garage layouts?
Yes, the design is highly customizable. Both the power unit and control panel positions can be adjusted to fit specific space requirements and environmental constraints.
What kind of maintenance does the cable system require?
The design includes increased pulley diameters to reduce cable fatigue and special protective devices to prevent loosening, which significantly extends the service life and reduces maintenance frequency.
Is the lift protected against rust and corrosion?
Absolutely. The entire surface is treated with a high-quality powder coating that provides a durable, aesthetic finish while protecting the steel from corrosion.
Does the lift accommodate vehicles with different widths?
Yes, the runway design is flexible enough to accommodate both wide and narrow vehicles, allowing for easy entry and exit of various car types.
