CE Certification Underground Pit Parking Stacker Lift System for 2 4 Cars Manufacturer, Product

The underground parking garage lift is a high-efficiency, space-saving solution designed to maximize parking capacity in urban and residential areas with limited space. By using hydraulic or mechanical lifting systems, vehicles can be stacked vertically across multiple levels, allowing more cars to be accommodated in the same footprint.

Ideal for condominiums, office buildings, and commercial properties, these lifts provide secure, convenient, and efficient vehicle storage. Equipped with user-friendly controls, sensors, and safety mechanisms, they ensure smooth and reliable operation.

By utilizing vertical space, underground parking lifts reduce surface congestion, lower construction costs, and increase property value, making them an excellent choice for space-constrained environments where efficient land use and functionality are critical.

Product Description

Products Feature

  • Parking solutions for basement garages in residential and commercial buildings.
  • The galvanized wave plate, paired with diamond plates, provides a better parking experience.
  • Directly driven by dual master-slave hydraulic lifting cylinders.
  • Independent hydraulic power unit and control panel.
  • The load-bearing capacity can reach 2000 kg for sedans.
products features 1
  • Automatically shuts down once the operator releases the key switch.
  • Suitable for independent parking. A single platform can park two cars, and a double platform can park four cars.
  • All parking levels can be accessed horizontally.
  • Low operating costs. The platform is driven by gravity when descending, eliminating the need for an electric motor.
  • Professional packaging and delivery ensuring products are delivered intact.
products features 2

Specifications

Feature Model CPL-2 Model CPL-4
Lifting Capacity 2000kgs 4000kgs
Lifting Height 1885mm 1885mm
Usable Platform width 2237mm 4502mm
Overall Height 4270mm 4270mm
Overall Length 5078mm 5078mm
Overall Width 2696mm 4776mm
Power Supply/Motor Capacity 380V, 50Hz / 60Hz, 3Ph, 5.5Kw
Lock Release Electric Release
Drive Mode Hydraulic Drive + Chain

Drawing & Case

drawing
cases-1
cases-2
cases-3

Frequently Asked Questions

Where can this parking system be installed?
This system is ideal for basement garages in both residential and commercial buildings, providing efficient space utilization.
What is the maximum lifting capacity?
The system supports up to 2000kg for the single platform (CPL-2) and up to 4000kg for the double platform (CPL-4).
Is the operation of the lift safe?
Yes, it features an automatic shut-down safety mechanism that stops the lift immediately when the operator releases the key switch.
How many cars can be parked on one unit?
A single platform can accommodate two cars, while a double platform design allows for four cars to be parked.
Does the system require high energy consumption?
No, it has low operating costs. The platform uses gravity to descend, which means the electric motor does not need to run during lowering.
What are the platform materials?
The system uses galvanized wave plates paired with diamond plates to ensure durability and a high-quality parking experience.
